CM510-62X
Product Features
·RS232 interface ·RS485 interface ·RS422 interface ·TTL interface
The device has an Online indicator pin, indicating when the device is Online or offline. Customers can use this pin, and they can also know when the device is Online or offline according to the status of this pin. The device provides an ACTIVE wake up pin. Customers can wake up a dormant device using this pin to achieve low power consumption.
Model No. | Network | Item | Interface | Dimension |
CM510-62G | GPRS | DTU | RS232、RS485 | 100x62x24 mm |
CM510-62C | CDMA | DTU | RS232、RS485 | 100x62x24 mm |
Technical Parameter
CM510-62X | |
Serial Port | Data bits: 8 bits Stop bits: 1, 1.5, 2 Parity bit: no parity, odd parity, even parity Serial port rate: 300bps ~ 115200bps Flow control bit: no flow control 1*RS485 interface, 1*RS232 communication interface |
Indicator Light | Online / ACT / Power |
Antenna Interface | Standard SMA female interface, 50 ohm; optional 3M/5M/10M/15M antenna extension cable, meet the different needs of customers |
SIM/UIM | 1.8V/3V/5V standard push-rod SIM card slot, built-in 15KV ESD protection |
Power Interface | Standard 3-pin locomotive power socket |
Powered By | |
Item | Description |
Recommended Power Supply | DC9V/1330mA |
Operating Voltage | Wide voltage design, DC7V to DC35V power supply can directly supply power to the device; and built-in power reverse protection and overvoltage and overcurrent protection |
Power Comsumption | |
Item | Description |
Average Communication Current | 60mA@+12VDC |
Instantaneous Peak Current: | 25mA@+12VDC |
Standby Average Current | 25mA@+12VDC |
Physical Characterisitics | |
Item | Description |
Shell | Metal shell: anti-radiation, anti-interference; shell and system security isolation, lightning protection design; meet the power requirements of safety regulations; protection rating IP41; particularly suitable for harsh industrial control environments. |
Current | 100x62x24 mm(not including the antenna and the fixed parts) |
Weight | 0.41kg |
Other Parameters | |
Item | Description |
Operating Temperature | （-25 ºC ~+65ºC） |
Storage Temperature | （-40~+85ºC） |
Relative Humidity | 95%(No condensation) |
Product Size
Selection Guide
Model NO. | CM510-62G | CM510-62C |
Standards and Frequency Bands | GSM/GPRS 850/900/1800/1900MHz CDMA 800MHz GPRS multi-slot class 12/10 GPRS mobile station class B Meet the GSM 2/2+ standard | CDMA 800MHz |
The theory of bandwidth |
| Theoretical bandwidth: data transmission, maximum 85.6 kbps (uplink\downlink rate); |
Transmit Power | Class 4 （2 W @850/900 MHz） Class 1 （1 W @1800/1900MHz） | Class 4 （2 W @850/900 MHz） Class 1 （1 W @1800/1900MHz） |
Receiver Sensitivity | <-109dBm | <-109dBm |
Application Scheme
1. Detection industry applications (pollution, meteorology, water pattern, water conservancy, earthquake, etc.)
2. Network management monitoring industry applications (gas pipe network, oil pipe network, heating network monitoring, water pipe network monitoring, etc.)
3. Oilfield monitoring, street light control, traffic control, vehicle guidance
4. Application cases in the power industry (power distribution monitoring, grid automation, automatic meter reading, grid dispatching)
